Steam Sterilizer Benchtop Type, Class –B Cycle, with pre & post vacuum system.

It is a practical small sterilizer that can effectively sterilize all medical equipment. The square chamber is fitted to allow the maximum space to be used.

Sterilizer Temp.: 110℃ ~ 135℃

Capacity: 12L / 24L / 40L

Model: LAC-1011SVM, LAC-1021SVM, LAC-1031SVM

Share Now

Product Category

Overview

A steam sterilizer, commonly known as an autoclave, is a device used in various industries and fields, including healthcare, laboratories, and manufacturing, to sterilize equipment, instruments, and other objects. It uses high-pressure steam to kill or eliminate microorganisms such as bacteria, viruses, fungi, and spores, making the sterilized items safe for use.

The Steam Sterilizer Benchtop Type Autoclave manufactured by Daihan Labtech is a specific type of autoclave designed for laboratory and research applications. Daihan Labtech is a well-known manufacturer of laboratory equipment and instruments, including autoclaves, centrifuges, incubators, and more.

Here are some key features and characteristics you might find in a benchtop autoclave from Daihan Labtech.

	Class B sterilization cycle Pre vacuum for air removal with 3 stage pulsate steam penetration post vacuum for vacuum drying and HEPA filtered air cooling Any type of medical device, such as packaged or unpaved solid devices, liquid or hollow instruments
	Reinforced and electro-polished squared chamber High quality polished stainless steel square chamber for excellent corrosion resistance, long lasting and efficient in space using (Option: STS 316L chamber) 고품질 광표면 #304 스테인리스스틸로 제작된 사각비가 뛰어난 공간 활용성을 제공 (STS316L옵션)
	Built-in reservoir with water saving re-circulation system provides for automatic water filling into chamber with level sensor
	0.2 μm HEPA filter is installed for clean air to flow into the chamber to protect from air contamination
	Electro polished stainless steel square chamber and silicone gasket with slopped platform design for excellent sterilization performance
	Manual handle door lock 90° Swift turn handle locking sealed with steam pressure absorbable square silicone gasket provides for safe and convenient use.
	Full automatic operation by pre / user set programmed mode LCD digital controller with self diagnostic for error and alarm function
	Detachable shelf frame with sturdy wire tray for easy cleaning and excellent drying performance

Compact Size: Benchtop autoclaves are designed to be smaller and more space-efficient than larger autoclaves. They are suitable for laboratories with limited space.

Steam Sterilization: Like other autoclaves, this benchtop model uses high-pressure steam to sterilize laboratory equipment, glassware, and other items.

Digital Controls: These autoclaves typically come equipped with digital control panels that allow users to set and monitor temperature, pressure, and sterilization cycles.

Safety Features: Modern benchtop autoclaves are equipped with multiple safety features to ensure the safety of users and prevent accidents.

User-Friendly Interface: The control interface is designed to be user-friendly and easy to operate, making it suitable for researchers and laboratory personnel.

Quick Sterilization: Benchtop autoclaves are known for their relatively quick sterilization cycles, making them ideal for labs that need to sterilize equipment frequently.

Automatic Drying: Some models may include automatic drying cycles to remove moisture from sterilized items after the sterilization process.

Multiple Sterilization Programs: Depending on the specific model, these autoclaves may offer various sterilization programs for different types of materials and loads.

Stainless Steel Construction: The sterilization chamber is typically made of stainless steel, which is corrosion-resistant and easy to clean.

Daihan Labtech Quality: Daihan Labtech is a reputable manufacturer known for producing high-quality laboratory equipment, so their benchtop autoclaves are likely to be reliable and well-built.

Safety device

Automatic over pressure release valve
Overheating and temperature protector
Visible and audible alarm for errors
Automatic dual door locking system
Door is not opened when the chamber is pressurized
If the door is not completely closed, it will not start
Safety pressure release valve&hot water/ steam cooling device
Low water level sensor and resevoir and alarm lamp 9. Electric leakage and over current ciruit breaker

Fully automatic operation with color touch screen with LED process display 7 in. touch screen controller is equipped to provide easy and convenient operation Self-diagnostic and error display system alerts, displays error codes, and stops operating with automatic ventilation in case of any malfunction For safety of the users, the door will not open at the end of cycle if the chamber is pressurized Manual door locking system to ensure user safety

Specification

Dimensions (WXHXDmm)	MODEL	LAC-1011SVM	LAC-1021SVM	LAC-1031SVM
	Square chamber	200 X 200 X 315	270 X 230 X 400	300 X 300 X 450
	Overall	430 x 430 x 570	495 x 440 x 650	527 x 510 x 710
	Tray (2 EA)	184 X 30 X 288	255 X 30 X 363	287 X 30 X 406
Capacity	Chamber	12 L	24 L	40 L
Heater		1.5 kW	2.5 kW	2.5 kW
Pressure vessel	/ Gasket Reinforced and electro polished square chamber / Silicone square gasket
Sterilization	Temperature		110°C 135°C
	Pressure		0.4 ~ 2.3 bar
	Mode	Unwrapped 1 & 2,	Wrapped 1 & 2, Liquid, Bowie-dick,	User program
Vacuum pump	(50Hz / 60Hz)	20/23 LPM	20/23 LPM	35 LPM
Controller		Microprocessor	program controller with	LCD monitor
Material	Chamber	Stainless	steel 304 (standard) / STS 316L	(option)
	Exterior		Epoxy powder coated steel
	Door	Stainless steel	plate STS 304 (standard) / STS	316L (option)
Electric supply	Voltage	110	V, 60 Hz or 220 V, 50/60 Hz 1	Phase
	Consumption(220V)	6.8 A	12 A	12 A
Weight (approx.)	Net	52 kg	62 kg	77 kg
